Automobile-qualified High-reliability Isolated Dual-channel Gate Drivers without DT Pins

The NSi6622-Q1 is a series of highly reliable isolated dual-channel gate driver ICs, which can be designed to drive power transistors with switching frequency up to 2MHz. Each output can source and sink up to 4A/6A with fast propagation delay of 25ns and the maximum delay matching of 5ns. The NSi6622Q1 provides 5700Vrms isolation in SOIC16 (300mil) and SOIC14 (300mil) wide-body packages. The minimum common mode transient immunity (CMTI) of 100kV/us improves system robustness. The maximum supply voltage of the driver is 28V, and the input side accepts supply voltages from 2.7V to 5V. All supply voltage pins support undervoltage lockout (UVLO). With all these outstanding features, NSI66x2 is suitable for switching power supply systems which require high reliability, high power density and high efficiency.

Product Features

•  Isolated dual-channel driver

•  Input power supply voltage:  2.7V to 5.5V

•  Driver-side power supply voltage: up to 28V with UVLOV

•  Peak source and sink current 4A/6A

•  High CMTI: ±100KV/μs

•  Typical propagation delay: 19ns

•  Maximum delay matching: 5ns

•  Maximum pulse width distortion: 6ns

•  Acceptable minimum input pulse width: 20ns

•  Operation temperature: -40℃~125℃

•  AEC-Q100

•  Package type

    SOIC14 wide-body

    SOIC16 wide-body

Safety Certificate

• UL1577 certification:

   SOW16: 5.7kVrms for 1 min.

   SOW14: 5.7kVrms  for 1 min.

• CQC certification:  Comply with GB4943.1-2011

     • CSA certification: Components conform to 5A

     • VDE certification: DIN V VDE V 0884-11: 2017-1


•  Vehicle charger

•  Vehicle DCDC

•  PTC

•  Compressor

Functional Block Diagram
