Brushed DC Motor Integrated Driver

NOVOSENSE brushed DC motor drivers involve a variety of voltage and current levels with integrated power tube, providing motor drive system design featuring miniaturization and high efficiency. At the same time, the chip solution simplifies the system design and provides high-precision current sampling, providing all-round protection and diagnostic functions for the output load, which can be widely used in industrial and automotive terminal applications.

View All Products

  • Load Type
    Brushed DC motor
    Brushed DC motor/Stepping/LED
  • Driver Type
    Fully-integrated Brushed DC Driver
  • Rds (on) (HS+LS) mΩ
    520
    1500
  • Peak Current (A)
    1.3
    3.6
  • Number of Half-bridge Channels
    2
    6
    8
  • Vmin(V)
    4.5
    5
  • Vmax(V)
    40
  • Integrated Current Detector
    -
    No
    Yes
  • Interface
    Parallel
    SPI
  • Feature
    Over-current protection, over-temperature protection, under-voltage protection
    Over-current protection, over-temperature protection, under-voltage protection and output diagnosis
  • Operation Temperature (°C)
    -40~125
  • Qualification
    Industrial
    Automobile
  • Package
    HSOP8
    HTSSOP24
  • Load diagnosis
    YES
    NO

show 10 devices

Part Number Load Type Driver Type Rds (on) (HS+LS) mΩ Peak Current (A) Number of Half-bridge Channels Vmin(V) Vmax(V) Integrated Current Detector Interface Feature Operation Temperature (°C) Qualification Package Load diagnosis
NSD7310-DHSPR
Brushed DC motor
Fully-integrated Brushed DC Driver
520
3.6
2
5
40
No
Parallel
Over-current protection, over-temperature protection, under-voltage protection
-40~125
Industrial
HSOP8
NO
NSD7310-Q1DHSPR
Brushed DC motor
Fully-integrated Brushed DC Driver
520
3.6
2
5
40
No
Parallel
Over-current protection, over-temperature protection, under-voltage protection
-40~125
Automotive
HSOP8
NO
NSD7310A-DHSPR
Brushed DC motor
Fully-integrated Brushed DC Driver
520
3.6
2
5
40
Yes
Parallel
Over-current protection, over-temperature protection, under-voltage protection
-40~125
Industrial
HSOP8
NO
NSD7312-DHSPR
Brushed DC motor
Fully-integrated Brushed DC Driver
520
3.6
2
5
40
No
Parallel
Over-current protection, over-temperature protection, under-voltage protection, fault report
-40~125
Industrial
HSOP8
NO
NSD7312A-DHSPR
Brushed DC motor
Fully-integrated Brushed DC Driver
520
3.6
2
5
40
Yes
Parallel
Over-current protection, over-temperature protection, under-voltage protection, fault report
-40~125
Industrial
HSOP8
NO
NSD7312-Q1HSPR
Brushed DC motor
Fully-integrated Brushed DC Driver
520
3.6
2
5
40
No
Parallel
Over-current protection, over-temperature protection, under-voltage protection, fault report
-40~125
Automotive
HSOP8
NO
NSD7312A-Q1HSPR
Brushed DC motor
Fully-integrated Brushed DC Driver
520
3.6
2
5
40
Yes
Parallel
Over-current protection, over-temperature protection, under-voltage protection, fault report
-40~125
Automotive
HSOP8
NO
NSD8308-Q1HTSXR
Brushed DC motor/Stepping/LED
Fully-integrated Brushed DC Driver
1700
1.3/1.7
8
4.5
40
-
SPI
Over-current protection, over-temperature protection, under-voltage protection, fault report
-40~125
Automotive
HTSSOP24
Yes
NSD8306A-Q1HTSXR
Brushed DC motor/Stepping/LED
Fully-integrated Brushed DC Driver
1700
1.3
6
4.5
40
-
SPI
Over-current protection, over-temperature protection, under-voltage protection, fault report
-40~125
Automotive
HTSSOP24
Yes
NSD8306-Q1HTSXR
Brushed DC motor/Stepping/LED
Fully-integrated Brushed DC Driver
1700
1.3/1.7
6
4.5
40
-
SPI
Over-current protection, over-temperature protection, under-voltage protection, fault report
-40~125
Automotive
HTSSOP24
Yes

For more product information, please contact us.
