Multi Channel Low Side Driver

NOVOSENSE multi-channel low-side drivers focus on intelligent low-end driver solutions, providing a variety of different channels and current options, supporting 12V and 24V application scenarios in harsh environments, with the highest withstand voltage of 55V. Fully qualified and equipped with protection features and enhanced diagnostics, the products can be used in industrial automation and automotive applications.

View All Products

  • Load Type
    Relay/solenoid
  • Driver Type
    Fully-integrated low-side driver
  • Rds (on) (LS) mΩ
    260
  • Peak Current (A)
    3
  • Number of Low-side Channels
    4
  • Vmin(V)
    8
  • Vmax(V)
    55
  • Control Interface
    Parallel
  • Operation Temperature (°C)
    -40~125
  • Qualification
    Industrial
  • Package
    HTSSOP16
    HTSSOP20
  • LDO
    YES
    NO

show 4 devices

Part Number Load Type Driver Type Rds (on) (LS) mΩ Peak Current (A) Number of Low-side Channels Vmin(V) Vmax(V) Control Interface Feature Operation Temperature (°C) Qualification Package LDO
NSD5604E-DHTSTR
Relay/solenoid
Fully-integrated low-side driver
260
3
4
8
55
Parallel
Over-current protection, over-temperature protection, under-voltage protection, clamp, configurable current limit point
-40~125
Industrial
HTSSOP20
NO
NSD5604-DHTSPR
Relay/solenoid
Fully-integrated low-side driver
260
3
4
8
55
Parallel
Over-current protection, over-temperature protection, under-voltage protection, clamp
-40~125
Industrial
HTSSOP16
NO
NSD5604NE-DHTSTR
Relay/solenoid
Fully-integrated low-side driver
260
3
4
8
55
Parallel
Over-current protection, over-temperature protection, under-voltage protection, clamp and configurable current limiting point
-40~125
Industrial
HTSSOP20
YES
NSD5604N-DHTSPR
Relay/solenoid
Fully-integrated low-side driver
260
3
4
8
55
Parallel
Over-current protection, over-temperature protection, under-voltage protection and clamp
-40~125
Industrial
HTSSOP16
YES

For more product information, please contact us.
